IDEC MICRO/I HG1G-4VT22TF Series - Page 298

3 Project Settings Dialog Box
4-44 WindO/I-NV4 User’s Manual
When USB2(USB-A) is selected under Interface Configuration
When USB1(USB-B) or USB(USB-B) is selected under Interface Configuration
The items displayed in the Interface vary based on the model.
■ Default
Returns the configured values to their default values.
*1 HG5G/4G/3G/2G-V, HG4G/3G, HG2G-5F only
Function: Selects the function used by the USB interface (Type A) from the following.
N/A, User Communication 1, User Communication 2, User Communication 3
This communication interface is not used when N/A is selected.
HG5G/4G/3G/2G-V, HG4G/3G, HG2G-5F, HG1G/1P: USB1(USB-B)
HG2G-5T: USB(USB-B)
Function:
Selects the function used by the USB interface (Mini-B) as N/A or Printer.
*1
This communication interface is not used when N/A is selected.
