WindO/I-NV4 User’s Manual 8-127
6 Multi-Button
8
Buttons
Properties of Script for Multi-Functions Dialog Box
Sets the script for the Multi-Button.
■ Command Name
Enter a name for the command. The maximum number is 20 characters.
■ Script ID
Specify the script ID (1 to 32000) of the script to operate.
Script Manager will open when is clicked. Select a script from the script list.
For details, refer to Chapter 20 “2.2 Script Manager” on page 20-7.
■ Script Name
Displays the name of the script selected in Script Manager.
■ (Script)
Displays the contents of the script selected in Script Manager.
Once this area is double clicked, the Script Editor will open and editing can be done.
For details, refer to Chapter 20 “2.3 Script Editor” on page 20-12.
To Next Page
