1 WindO/I-NV4 Specifications
2-26 WindO/I-NV4 User’s Manual
2 Enter the name of the drawing object in Picture Name.
The maximum number is 256 characters.
3 Click OK.
The drawing object is saved in Picture Manager.
You cannot use the following characters in the picture name.
\ / : , ; * ? " < > |
Configures the image processing in Options. For details, refer to “Picture Name Setting Dialog Box” on
page 2-36.
If a picture contains transparency or a picture is imported with the option of enabling the transparency, the
transparency range is displayed in magenta (R: 255, G: 4, B: 255).
