IDEC MICRO/I HG1G-4VT22TF Series - Page 663

WindO/I-NV4 User’s Manual 10-57
3 Picture Display
10
Data Displays
• Switch and display pictures at a regular interval
• Move the picture position by values of device addresses
MICRO/I
Picture List
5 x 100 ms
5 x 100 ms
5 x 100 ms
Pic0
Pic1
Pic2
External device
MICRO/I
Display picture at X 0, Y 0
Move picture to X 300, Y 250
Move picture to X 600, Y 500
X-coordinate D100=
0
Y-coordinate D101=
X-coordinate D100=
Y-coordinate D101=
X-coordinate D100=
Y-coordinate D101=
0
300
250
600
500
