3: I
NSTALLATION
AND
W
IRING
3-26 FC6A S
ERIES
M
ICRO
S
MART
A
LL
-
IN
-O
NE
T
YPE
U
SER
’
S
M
ANUAL
FC9Y-B1722
Closing the SD Memory Card Cover
1. Close the SD memory card cover and push it until it clicks.
Inserting and Removing the SD Memory Card
The following procedure describes how to insert and remove the SD memory card.
Inserting the SD Memory Card
1. Unlock and open the SD memory card cover.
For details, see "Opening the SD Memory Card Cover" on page 3-25.
2. With the missing corner of the SD memory card positioned up (pins on the right side), push the SD memory card cover straight
in until it clicks.
Notes:
• Take care with the direction that the SD memory card is pushed in.
• Turn off the write protect switch on the SD memory card that will be inserted into the FC6A Series MicroSmart.
3. Close the SD memory card cover and push it until it clicks.
For details, see "Closing the SD Memory Card Cover" on page 3-26.
