9: F UNCTIONAL M ODULES
9-4 FC6A S ERIES M ICRO S MART A LL - IN -O NE T YPE U SER ’ S M ANUAL FC9Y-B1722
(1) Signal Type
The signal type that can be set differs according to the analog module model. Select the analog module that corresponds to the
user application and set the signal type. The signal type is the type of analog input to measure. There are 24 types of signal
types for the analog inputs, which are detailed as follows.
Yes: Supported,
―: Not supported
Signal Type FC6A-J2C1 FC6A-J4A1 FC6A-J8A1 FC6A-J4CN1 FC6A-J8CU1 FC6A-L06A1 FC6A-L03CN1
Unused
*1
Yes Yes Yes Yes Yes Yes Yes
0 to 10 V Yes Yes Yes Yes ― Yes Yes
-10 to +10 V Yes Yes Yes Yes ― Yes Yes
0 to 20 mA Yes Yes Yes Yes ― Yes Yes
4 to 20 mA Yes Yes Yes Yes ― Yes Yes
Type K thermocouple ―――Yes Yes ― Yes
Type J thermocouple ―――Yes Yes ― Yes
Type R thermocouple ―――Yes Yes ― Yes
Type S thermocouple ―――Yes Yes ― Yes
Type B thermocouple ―――Yes Yes ― Yes
Type E thermocouple ―――Yes Yes ― Yes
Type T thermocouple ―――Yes Yes ― Yes
Type N thermocouple ―――Yes Yes ― Yes
Type C thermocouple ―――Yes Yes ― Yes
Pt100 ―――Yes ――Yes
Pt1000 ―――Yes ――Yes
NI100 ―――Yes ――Yes
NI1000 ―――Yes ――Yes
NTC thermistor ――――Yes ――
PTC thermistor ――――Yes ――
PTC thermistor
(threshold)
*1
――――Yes ――
Resistance measurement ――――Yes ――
Expansion 0 to 20 mA ――Yes ――― ―
Expansion 4 to 20 mA ――Yes ――― ―
*1 Channels that are set to unused are not scanned.
The circuit is setup the same as when signal type: 0 to 10 V is selected.
0 is always stored in the analog data storage data registers for channels that are set to unused.
