FC6A S ERIES M ICRO S MART A LL - IN -O NE T YPE U SER ’ S M ANUAL FC9Y-B1722 9-5
9: F UNCTIONAL M ODULES
(2) Data Type
The analog input value can be handled as the set data type. There are four data types for the analog inputs.
Yes: Supported,
―: Not supported
(3) Minimum and maximum values
The analog input values are stored in data registers. The stored minimum and maximum values are determined by the set signal
type and data type. A parameter setting error occurs when a value is set that exceeds the minimum or maximum value.
The minimum and maximum values that correspond to the signal type and data types are as follows.
Data Type FC6A-J2C1 FC6A-J4A1 FC6A-J8A1 FC6A-J4CN1 FC6A-J8CU1 FC6A-L06A1 FC6A-L03CN1
Binary data Yes Yes Yes Yes Yes Yes Yes
Optional range Yes Yes Yes Yes ― Yes Yes
Celsius
*1
Yes Yes Yes Yes ― Yes Yes
Fahrenheit
*1
Yes Yes Yes Yes ― Yes Yes
Resistance
*2
――Yes ――― ―
*1 Can only be set when the signal type is thermocouple, resistance thermometer or NTC thermistor.
*2 Resistance when using the FC6A-J8CU1 and the signal type is set to PTC thermistor and resistance.
Signal Type
Data Type
Binary Data Optional Range
*1
Celsius Fahrenheit Resistance
0 to 10 V 0 to 65,535
*2
-32,768 to 32,767 ―――
-10 to +10 V -32,768 to 32,767
*2
-32,768 to 32,767 ―――
0 to 20 mA 0 to 65,535
*2
-32,768 to 32,767 ―――
4 to 20 mA 0 to 65,535
*2
-32,768 to 32,767 ―――
Type K thermocouple 0 to 65,535 -32,768 to 32,767 -2,000 to 13,000 -3,280 to 23,720 ―
Type J thermocouple 0 to 65,535 -32,768 to 32,767 -2,000 to 10,000 -3,280 to 18,320 ―
Type R thermocouple 0 to 65,535 -32,768 to 32,767 0 to 17,600 320 to 32,000 ―
Type S thermocouple 0 to 65,535 -32,768 to 32,767 0 to 17,600 320 to 32,000 ―
Type B thermocouple 0 to 65,535 -32,768 to 32,767 0 to 18,200 320 to 33,080 ―
Type E thermocouple 0 to 65,535 -32,768 to 32,767 -2,000 to 8,000 -3,280 to 14,720 ―
Type T thermocouple 0 to 65,535 -32,768 to 32,767 -2,000 to 4,000 -3,280 to 7,520 ―
Type N thermocouple 0 to 65,535 -32,768 to 32,767 -2,000 to 13,000 -3,280 to 23,720 ―
Type C thermocouple 0 to 65,535 -32,768 to 32,767 0 to 23,150 320 to 41,990 ―
Pt100 0 to 65,535 -32,768 to 32,767 -2,000 to 8,500 -3,280 to 15,620 ―
Pt1000 0 to 65,535 -32,768 to 32,767 -2,000 to 6,000 -3,280 to 11,120 ―
NI100 0 to 65,535 -32,768 to 32,767 -600 to 1,800 -760 to 3,560 ―
NI1000 0 to 65,535 -32,768 to 32,767 -600 to 1,800 -760 to 3,560 ―
NTC thermistor 0 to 65,535 -32,768 to 32,767 -900 to 1,500 -1,300 to 3,020 ―
PTC thermistor 0 to 65,535 -32,768 to 32,767 ――100 to 10,000
PTC thermistor (threshold) 1/2/4 ――――
Resistance measurement 0 to 65,535 -32,768 to 32,767 ――100 to 32,000
Expansion 0 to 20 mA 0 to 4,095 -32,768 to 32,767 ―――
Expansion 4 to 20 mA 0 to 4,095 -32,768 to 32,767 ―――
*1 The minimum and maximum values can be set only when the data type is set to optional range. Set the minimum and maximum values
between -32,768 and 32,767.
*2 The minimum and maximum values of FC6A-J4A1, FC6A-J8A1, and FC6A-L06A1 are as follows.
Signal Type
Data Type
Binary Data
0 to 10 V 0 to 4,095
-10 to +10 V -2,048 to 2,047
0 to 20 mA 0 to 4,095
4 to 20 mA 0 to 4,095
