9.4 Display web visualisation
42437
To display the created web visualisation:
Requirements:
> PC/laptop is connected to the configuration interface (X3) of the device (→ device manual: Configuration
interface: connection concepts)
CODESYS Standard PLC appliation
► Download Standard PLC application with web visualisation to the device and start it (→Download standard
application to AC4S (→ S. 102)).
► On PC/laptop: Start web browser.
► Enter the following in the address line and press [ENTER] to confirm:
http://<IP address-of-the-device>:<8080>/myvisu.htm
myvisu is the user-defined name of the visualisation (→Change properties of the web
visualisation (→ S. 66)).
> Web browser shows the web visualisation of the device.
ifm system solution
► Install the ifm system solution on the device and start it (→ device manual, Install single / basis app or
Install multi app).
► Display informationen about the installed ifm app (→ device manual, Display informationen about
installed ifm apps).
► Call hyperlink of the ifm app.
> Web browser shows the web visualisation of the ifm system solution.
