8.1 Objects of a safe application
43095
All objects of a safe application are listed as sub-elements of the node [SafetyApp] in the safety area
of the device tree. In the basic configuration the safety-relevant application contains the following
objects:
[SafetyApp] is the container for objects of a safe application and provides access to the editor of the safety application
object
→Pin safe project (→ S. 75)
[Library Manager] provides access to the certified safety libraries
→Use safety functions of CODESYS (→ S. 79)
→Use safety functions of the ifm AS-i package (→ S. 76)
[Logical I/Os] contains following objects:
 Logical exchange devices for the data exchange between Standard PLC and fail-safe PLC
→Data exchange between standard PLC and fail-safe PLC (→ S. 82)
 Logical Devices of the inserted safe AS-i slaves
→Configure safe AS-i slaves (→ S. 24)
 Logical devices of the safe devices at local I/O interface
→Configure safe devices at local I/O interface (→ S. 32)
[SafetyPOU] contains the program code of the safe application
→Create safe application (→ S. 72)
[Safety Task] provides access to the configuration options of the safety task
→Configure safety task (→ S. 100)
