8.6.1 Note on the size of the exchange objects
43008
The amount of data that can be transmitted with the failsafe network variables is limited. The following
restrictions apply:
 mamimum number of connections sender >>> receiver: 10
 maximum number of bytes per connection sender >>> receiver: 32
 maximum number of bytes in input and output area: 256 each
The required number of bytes for each AC4S is derived from the following equations:
 configured sender lists ([Safety network variable list (sender)])
 output area (data from failsafe PLC to standard PLC): number of receivers * (user data*2+3)
bytes
 input area (data from standard PLC to failsafe PLC): number of receivers * 7 bytes
 configured receiver lists ([Safety network variable list (receiver)])
 output area (data from failsafe PLC to standard PLC): 7 bytes
 input area (data from standard PLC to failsafe PLC): (user data*2+3) bytes
The size of the user data results from the number of created failsafe variables. Depending on the data
type used, failsafe variables require the following storage capacities:
Variable type
Size
SAFEBOOL
SAFEBOOL variables are bundled in DAFEWORD variables; in each SAFEWORD up to 16
SAFEBOOL variables can be transfer
 1...16 variables = 2 bytes
 17...32 variables = 4 bytes
 33...48 variables = 6 bytes
SAFEINT
1 variable = 2 bytes
SAFEWORD
1 variable = 2 bytes
For broadcast / multicast of varaible lists the above mentioned rules also apply.
