6.5 Configure standard devices at local I/O interface
43249
Standard devices are added without logical device to the CODESYS project. When the device has
been properly connected to the local I/O interface, the programmer can access the process data
directly from the safe application via function blocks.
Access to non-safe inputs and outputs of the local I/O interface is made only via the fail-safe
PLC of AC4S.
 To access the input/output data of the non-safe devices at the local I/O interface:
→Local I/O interface: Access non-safe inputs/outputs (→ S. 78)
 To transfer process data between Standard PLC and fail-safe PLC of AC4S:
→Data exchange between standard PLC and fail-safe PLC (→ S. 82)
>
6.6 Change IP settings
43400
► Familiarise yourself with the following CODESYS functions!
 Ethernet adapter configurator
→ Online help > Fieldbus support > Ethernet adapter configurator
The Ethernet configuration interfaces 1 (X3) and 2 (X8) must not be participants of the same
EtherNet subnet. Non-compliance may result in connection problems between the CODESYS
programming system and the device.
► Configure IP settings so that interfaces X3 and X8 are part of different Ethernet subnets.
To change the IP settings of the Ethernet configuration interfaces 1 (X3) and 2 (X8):
1 Select Ethernet interface
► In the device tree: Double click on the requested Ethernet interface (X3 or X8)
> The editor window shows the Ethernet device editor.
2 Change IP settings
► Change IP settings of the Ethernet interface.
> Save the project to apply changes.
