SmartPLC SafeLine AC4S with fieldbus interfaces
166
>
QuickSetupASi_Master
42519
Function block type:
Function block (FB)
Library:
ACnnnn_Utils.library
Symbol in CODESYS:
>
Description
42407
The FB executes the quick setup routine on the selected AS-i masters.
>
Input parameters
42603
Parameter
Data type
Description
Possible values
xExecute
BOOL
Control execution of the FB
FALSE
Don't execute FB
TRUE
Start one-time FB execution
xMaster1
BOOL
Select AS-i master 1 for quick setup
FALSE
No execution of quick setup,
AS-i configuration remains
unchanged.
TRUE
Execution of quick set up on
AS-i master
xMaster2
BOOL
Select AS-i master 2 for quick setup
FALSE
No execution of quick setup,
AS-i configuration remains
unchanged.
TRUE
Execution of quick set up on
AS-i master
