SmartPLC SafeLine AC4S with fieldbus interfaces
192
>
Output parameters
43078
Parameter
Data type
Description
Possible values
Ready
BOOL
Status of the FB processing
(validity of the output signals)
FALSE
FB not completely processed or
deactivated; signals are invalid
TRUE
FB completely processed; signals are
valid
Error
BOOL
Error indication
FALSE
No error
TRUE
Logical device is in the locked error
state S_ERROR
DiagCode
WORD
Diagnostic code of the internal
states of the controlled logical
device
Scope of the diagnostic code depends on the
controlled logical device: Description of the
selected logical device (→ Library
SF_LogicalInterfaces.library (→ S. 200))
Diagnostic codes:
 0x8000
Output = ON; HS_ACK = idle
 0x8002
Output = OFF; HS_ACK = idle
 0x8830
Output = ON; HS_ACK = OK
 0x8832
Output = OFF; HS_ACK = OK
 0x8840
Output = ON; HS_ACK = nOK
 0x8842
Output = OFF; HS_ACK = nOK
 0x8850
Output = ON; HS_ACK = RUN
 0x8852
Output = OFF; HS_ACK = RUN
>
