SmartPLC SafeLine AC4S with fieldbus interfaces
202
>
States of the input signals
43002
Depending on the type of logical device the following definitions apply:
 AS-i slaves
Safe AS-i input slaves transmit their input data as unambiguous code sequences. A code
sequence consists of 2 half-sequences with each half sequence representing a signal channel.
 Local I/O interface
At the local I/O interface each input represents a signal channel.
The combination of the two signal channels results in the following states and the respective state
events:
State
State / Description
Transition event
NoChan
The signal channels A and B are in the logical state FALSE
E_NoChan
ChanA_only
Signal channel A is in the logical state TRUE.
Signal channel B is in the logical state FALSE.
E_ChanA_Only
ChanB_only
Signal channel A is in the logical state FALSE.
Signal channel B is in the logical state TRUE.
E_ChanB_only
ChanAB
The signal channels A and B are in the logical state TRUE.
E_ChanAB
ChanInvalid*
The logical value of the signal channels is invalid (e.g. code sequence is incomplete,
code sequence invalid)
E_ChanInvalid
* ... Only available for logical devices for AS-i input slaves
>
Sequence of the signal changes
43043
The combination of the input signals "ChanA_only" and "ChanB_only" and the state of the parameter
"P_Chan_B_first" allows to define state transitions which consider the sequence of the signal change
at the input channels:
State / Description
Transition event
ChanA = TRUE UND ChanB = FALSE UND Chan_B_first = TRUE
E_ChanA; P_ChanB_first = TRUE
ChanA = TRUE UND ChanB = FALSE UND Chan_B_first = FALSE
E_ChanA; P_ChanB_first = FALSE
ChanB = TRUE UND ChanA = FALSE UND Chan_B_first = TRUE
E_ChanB; P_ChanB_first = TRUE
ChanB = TRUE UND ChanA = FALSE UND Chan_B_first = FALSE
E_ChanB; P_ChanB_first = FALSE
