IFM Electronic AC402S - Page 211

SmartPLC SafeLine AC4S with fieldbus interfaces
211
>
Parameter data
43072
Parameter
Data type
Description
Possible values
ASi_SlaveAdr
INT
Address of the AS-i slave
1
...
31
Slave address 1
...
slave address 31
ASi_Master
INT
AS-i master to which the AS-i
slave is connected
1
AS-i Master 1
2
AS-i Master 2
DisableLogging
BOOL
Transmission of the event
messages to OSC of the device
FALSE
Following states of the state diagram
are transmitted to the OSC: *
 S_ON
 S_OFF
 S_Test
 S_Error
 S_Init (HW-Error)
TRUE
Following states of the state diagram
are transmitted to the OSC:
 S_Test
 S_Error
 S_Init (HW-Error)
EnableStartupTest
BOOL
Control execution of the start-up
test
FALSE
No start-up test *
TRUE
Start-up test is executed; slave waiting
for start-up sequence OFF  ON
* ...
Default value
Process data
43127
Parameter
Data type
Description
Possible values
S_IN_indep
SAFEBOOL
Safe process signal
FALSE
safety function OFF
TRUE
safety function ON
>
