SmartPLC SafeLine AC4S with fieldbus interfaces
237
>
Parameter data
43058
Parameter
Data type
Description
Possible values
IN_Channel_A
INT
Local input to which sensor
channel A is connected.
1
...
8
Local input IN1
...
local input IN8
IN_Channel_B
INT
Local input to which sensor
channel B is connected.
1
...
8
Local input IN1
...
local input IN8
EnableIN_Test
BOOL
Evaluation of a test signal which
was created by a local output
FALSE
Test signal is ignored *
TRUE
Test signal is evaluated
DisableLogging
BOOL
Transmission of the event
messages to OSC of the device
FALSE
Following states of the state diagram
are transmitted to the OSC: *
 S_ON
 S_OFF
 S_Test
 S_Error
 S_Init (HW-Error)
TRUE
Following states of the state diagram
are transmitted to the OSC:
 S_Test
 S_Error
 S_Init (HW-Error)
EnableStartupTest
BOOL
Control execution of the start-up
test
FALSE
No start-up test *
TRUE
Start-up test is executed; slave waiting
for start-up sequence OFF  ON
* ...
Default value
>
Process data
43116
Parameter
Data type
Description
Possible values
S_IN_forced
SAFEBOOL
Safe process signal
FALSE
SAFE OFF
TRUE
Safe ON
>
