SmartPLC SafeLine AC4S with fieldbus interfaces
>
Digital output data
42440
To access the digital output data of the slaves at AS-i master 1:
► Device window: In the project tree, double-click on [ASi_1_binaryIO]
> Editor window shows a structured list of the digital output data:
► In column [Variable]: Mouse click on to make individual variables visible.
To access the digital output data of the slaves at AS-i master 2 in a system with 2 AS-i masters:
► Double-click on [ASi_2_binaryIO]
>
Analogue output data
42502
To access the analogue output data of the slaves at AS-i master 1:
► Device window: In the project tree, double-click on [ASi_1_analogOut]
> Editor window shows the structured list of the analogue output data:
► In column [Variable]: Mouse click on to make individual variables visible.
To access the analogue output data of the slaves at AS-i master 2 in a system with 2 AS-i masters:
► Double-click on [ASi_2_analogOut]
