C-COM Satellite Systems Inc. Page 10 of 164
2. Specifications
Dimensions: Width: 17.1” x Depth: 11.0Height: 2.0”
Weight: 9.9 lbs. (4.5 kg)
Operating Temperature: -20°C to +50°C
Elevation Output: 12VDC, 15A (Max.)/24 VDC, 8A
Azimuth Output: 12VDC, 10A (Max.)/24 VDC, 6A
Polarization Output: 12VDC, 3A (Max.)/24 VDC, 2A
Power Consumption (Idle): 12VDC @ 1A /24 VDC @ 0.5A
Universal AC Input: 100 240 VAC, 2.2 1.1 A, 50/60 Hz
Motor Control Connector: 9 Position Circular AMP Connector
Signal Input: Female DB26 Connector
GPS Connector: SMA (Sub-Miniature Version A)
Rx Connector: Type F RG6
PC Interface: USB Interface
Network Interface
Serial Interface
Web Interface
Front Panel Interface: Automatic and Manual Control Keypad
LCD Screen and Keypad Navigator
Tuner Specifications
RF Input Range: 950MHz to 2150MHz
Input Signal Level: -65dBm to 25dBm
Input/Output Impedance: 75 Ω
Symbol Rate: ~1 to 45Msps
**NOTE** Controller specifications include/cover model 7000B, 7000C, 7024A,
7024B and 7024C
3. Minimum Recommended PC Requirements
Operating System Windows XP, Vista, W7 and W8
CPU 2.0 GHZ
Memory (RAM) 1.0GB
MSN.Net Framework 3.5 installed
