C-COM Satellite Systems Inc. Page 72 of 164
HT - HTTP Interface
SN – SNMP Interface
UD – UDP Interface
NA - No modem interface applicable, this option is generally selected with the stand-alone service.
Locking and peaking onto satellite is based on the DVB Signal and not on the modem SNR value.
3 – Modem Delay Time
This allows users to delay Controller communication to allow slower modems to
catch up. The default setting is 0 – 1s user has option for a 10s delay.
4 – Modem Password/CD-KEY
If necessary, the user must enter the modem password into this area for
communication to be properly established. The default password is “P@55w0rd!”
which is based on most iDirect modem requirements. If no password is required,
this area should be left blank.
CD – Key must be entered instead of the password if iPSTAR Service is
selected.
7.6.5. TST
Fig. 53: Test Menu
Will allow for Demo Testing on all axes (elevation, azimuth, and
polarization) for a user specified angle range.
Deploys the antenna to a user specified azimuth, elevation, and
polarization position.
Will read the compass heading at a user specified elevation, azimuth,
and polarization target point.
Deploys the antenna to a user specified azimuth, elevation, and
polarization position without moving EL to 30˚ first, and without the extra
steps that exist in DPY.
Tests the compass’ heading and accuracy by rotating the antenna at
90° intervals and comparing the compass readings with the actual
antenna’s movement.
Performs an automatic ACP test for Hughes service.
E&A&P DPY DPYQ DPY_C
CP A_ACP M_ACP S_ACP
To Next Page
