C-COM Satellite Systems Inc. Page 73 of 164
Performs a manual ACP test for Hughes service.
This operation will stop the ACP test from continuing.
7.6.5.1. E&A&P
Fig. 54: Test/Demo EL,AZ, PL Configuration
1 – Elevation Range
Allows the user to set the start and stop angle of the elevation axis, as well as set
the specific speed for elevation movement. (E +20:70:7 –implies from angle 20 to
70 at speed 7)
2 – Polarization Range
Allows the user to set the start and stop angle of the polarization axis, as well as
set the specific speed for polarization movement. (P -60:60:7 –implies from angle
-60 to 60 at speed 7)
3 – Azimuth Range
Allows the user to set the start and stop angle of the azimuth axis, as well as set
the specific speed for azimuth movement. (A -180:180:7 –implies from angle -
180 to 180 at speed 7)
4 – Axis Selection and looping option
The first two characters refer to the axis selection (i.e. DD: D).
DD Disable Test for all axes
EL Perform test on the Elevation axis only
AZ Perform test on the Azimuth axis only
PL Perform test on the Polarization axis only
AA Perform tests on all the axes.
The third character refers to the looping intervals between tests (i.e. DD: D).
D Disables looping, test will only be performed once.
1 Infinitely loops with 3-seconds interval between tests.
2 Infinitely loops with 6-seconds interval between tests.
3 Infinitely loops with 9-seconds interval between tests.
4 Infinitely loops with 12-seconds interval between tests.
E +20:70:7 P-60: 60:7
A-180: 180:7 DD: D TST
