C-COM Satellite Systems Inc. Page 51 of 164
7.6.3.4. SM1
This menu allows for the configuration and saving of the Satellite Search Modes with a
total of 5 different configurable satellites, each can be configured with different RF
Search Mode parameters.
Fig. 35: “SM1” Search Mode Configuration Display
1 – RF Search Mode
N RF Mode is disabled; Y will be displayed when enabled.
N RF override mode (second digit) is disabled; O will be displayed when enabled.
RF Threshold (50) Value will be displayed here, this value is configurable.
2 – CP (Compass)
V Valid – The compass reading is functioning properly
N Normal – Full Search NOT selected, (nor is compass overridden).
O Override – the compass has been overridden, and direction entered manually considered
F Full Search – searches a full 360º search window, Fly-away systems (70 º), Full search
also overrides compass.
3 – Compass Heading
Compass Heading after Compass has been read.
Approximate Headings: North 354
East 87
South 176
West 265
Calibrate/Check Compass Routine see CPC under OPERATION or CP under
TST.
4 - AZ Search Window
The Search Window is the area of the sky which the iNetVu
®
Mobile System will
search for the desired Satellite. It uses a rectangular window and searches for
the Satellite using smaller concentric windows until the desired Satellite is found.
The window value represents the amount of degrees the antenna will search for
RF:N-O- 50
CP :N- 000 AZ_W :060
