iNetVu 7000 Series User Manual

C-COM Satellite Systems Inc. Page 152 of 164
12.3. Appendix 3: LCD Table Summary
Menu
Field
Explanation
MONITOR
MAIN
E (Angle)
Elevation Angle and Limit Indicators
A (Angle)
Azimuth Angle and Stow Limit Indicator
P (Angle)
P (Angle) – Polarization Angle and Stow Limit Indicator
GPS and CMPS
GPS Status Flag and Compass Status Flag (OO, OV, VO, FF)
ST
System Status (II, ST, PK, etc.)
RF/DVB (Value)
RF/DVB (U/L) – Receive RF/DVB Signal Value and Lock/Unlock Status
M (SNR) D/E
Modem Signal and Transmitter Status
Beacon Signal
Beacon Signal value, and locked or unlocked status of BR300L Receiver(optional)
EL
E (Angle)
Real Time Elevation Angle and Status
I/S
Real Time Current being drawn from the elevation motor @ the set speed
S (Value)
Elevation search window limit
Ad (Value)
Advanced Search Elevation Gap
C (Value)
Elevation angle at which the compass reading is taken
O (Value)
Elevation Offset used to obtain an accurate elevation reading
AZ
A (Angle)
Real Time Azimuth Angle and Status
I/S
Real Time Current drawn from the Azimuth motor @ the set speed
W (Value)
Azimuth search window limit
Z
AZ Zero AZ Axis
PL
P (Angle)
Real Time Polarization Angle and Status
I/S
Real Time Current drawn from the Polarization motor @ the set speed
O (Value)
Polarization offset
Z
PL Zero PL axis
GP
GPS (Status)
GPS Status (i.e. Normal, Overridden, or Failure)
LAT and LONG
Latitudinal and Longitudinal GPS Coordinates
V (Value)
GPS Velocity – indication of moving vehicle
H (Value)
GPS Heading
SM
RF Search Mode
RF mode status disabled or enabled (N or Y) – first field
RF Override
RF override status disabled or enabled (N or O) – second field
RF Threshold
RF Threshold value
RF/DVB (status)
RF or DVB value with LNB and Signal (N or L)
CP (Status)
Compass Status (i.e. Normal, Overridden, or Failure)
CP (Value)
Compass Heading taken after compass has been checked
AZ_W
Azimuth search window
S1
Sat No
Target Satellite (Sat0 to Sat 4)
Sat Long +
Hems.
Target Satellite Locations Longitudinal Value and Hemisphere
E (EL)
Target Antenna Elevation Value for Satellite acquisition
A (AZ)
Target Antenna Azimuth Value for Satellite acquisition with reference to True North
P (PL)
Target Antenna Polarization Value for Satellite acquisition
TP NUMBER
T0-T2 (Horizontal Receive) and T3-T5 (Vertical Receive) DVB Transponders
FREQUENCY
Satellite Transponder Frequency that DVB searches
SYMBOL RATE
Satellite Transponder Symbol Rate that DVB searches
CODE RATE
Satellite Transponder FEC (Code) Rate that DVB searches
LNB Power
LNB Power supplied to the LNB when searching for target satellite
S2 (Optional)
Ref. Sat Long +
Hems.
Reference Satellite Status, Locations Longitudinal Value and Hemisphere
E (EL)
Target Antenna Elevation Value for Satellite acquisition
A (AZ)
Target Antenna Azimuth Value for Satellite acquisition with reference to True North
P (PL)
Target Antenna Polarization Value for Satellite acquisition
