C-COM Satellite Systems Inc. Page 107 of 164
8.2.2.8. Maintenance Menu Buttons
The following buttons are available in the maintenance menu for multiple purposes
including, ease of use, troubleshooting, accessing data files and more.
Demo / Test
Opens System Test and Demo menu screen
Reset
Restarts the controller
Upload SatParameter
Loads all the Satellite Transponder information located in the
“iNetVu7000_SatParam” text file, into the 7000 Series Controller. The
user may modify the table with any DVB transponders that he/she
would like saved in the 7000 Series Controller, and click on this button
to upload the changes to the controller.
Download Log File
Downloads the log data from the 7000 Series Controller onto the
user’s PC. The user may select how much of the log file to upload
from the Controller section of this maintenance menu. The maximum
data a user may upload is 12 hours.
Load Firmware
Loads the iNetVu_Box.s19 firmware file into iNetVu
®
Controller
from the iNetVu program folder. By default this option is grayed out
and only available once the controller is in Boot Load mode. The
update process is displayed on screen and will notify the user when
the process is complete. The controller will be unavailable during this
time.
Note: If loading firmware or Satellite Parameter table via USB interface connection
with HN_KA modem type selected and the Application is open when controller is
first put in Firmware load mode; Application will close without any warning and
user must re-launch the Application to click on the Load Firmware button. The
Application will NOT close once Firmware updating has finished. It is
recommended to close the application prior to invoking Firmware update mode
when using HN_KA modem. Application will also close if USB communication is
lost.
