12.1. Appendix 1: Default Limits and Configuration Data Tables
Compass Reading Elevation
PLATFORM TYPES
A1800A
/B/C/E
A1500A/
B/C/E
A1200
A0980
A0740
A0660
COMPASS READING
ELEVATION
32
37
32
35
25
25
PLATFORM TYPES
A1810A
/B/C/E
A1801A
/B/C/E
A0180A
A1210A
A1201A
A1200Q
COMPASS READING
ELEVATION
32
32
32
32
32
32
PLATFORM TYPES
A0985A
A0985B
A0981A
A0755A
A0121
A0125A
COMPASS READING
ELEVATION
24
24
24
24
NA
NA
Table 1: Compass Reading Elevation Default Values
Elevation Offset
PLATFORM TYPES
A1800A/
B/C/E
A1200B/
A1500A/
B/C/E
A0980
A0740
A0660
EL OFFSET
45.00
42.00
31.00
31.00
35.00
PLATFORM TYPES
A1210A
A1201A
1200Q
A0121A
A0125A
EL OFFSET
60.5
17
11
15.5
15.5
A0985A
A0985B
A0981A
A0755A
EL OFFSET
18.5
18.5
18.5
20.5
Table 2: Default Elevation Offsets. All values are + 2  after Target Calibration.
