iNetVu 7000 Series User Manual

C-COM Satellite Systems Inc. Page 153 of 164
TP NUMBER
T0-T2 (Horizontal Receive) and T3-T5 (Vertical Receive) DVB Transponders
FREQUENCY
Satellite Transponder Frequency that DVB searches for ref. Satellite
SYMBOL RATE
Satellite Transponder Symbol Rate that DVB searches for ref. Satellite
CODE RATE
Satellite Transponder FEC (Code) Rate that DVB searches for ref. Satellite
LNB_P
LNB Power supplied to the LNB when searching for reference Satellite
MB
Modem (Status)
Status of communication between controller and modem (i.e. initializing, normal, etc.)
A (ACP Status)
Real Time ACP Status from the NOC
BR (Freq :
status))
Status and Frequency of the Beacon Receiver
IP
C_IP (Address)
Controller IP Address
M_IP (Address)
Modem IP Address
GW
S_IP (Address)
Controller Subnet IP Address
G_IP (Address)
Controller Gateway IP Address
OPERATION
S0/BLU/BM
Find Sat 0
Automatically Find and Lock on to configured satellite 0 or Blue Beam or Beam ID
S1/ORG
Find Sat 1
Automatically Find and Lock on to configured satellite 1 or Orange Beam
S2/PRP
Find Sat 2
Automatically Find and Lock on to configured satellite 2 or Purple Beam
S3/GRN
Find Sat 3
Automatically Find and Lock on to configured satellite 3 or Green Beam
S4
Find Sat 4
Automatically Find and Lock on to configured satellite 4, S4 returns system back to
auto mode when using front panel with Tooway modem.
TE
Enable Tx
Enable the Transmitter
TD
Disable Tx
Disable the Transmitter
AZC
Calibrate AZ
Calibrate the Azimuth Axis
PLC
Calibrate PL
Calibrate the Polarization Axis
CPC
Calibrate CP
Calibrate the Compass
CR
Restore
Compass
Automatically Restores Compass to Factory Calibrated state
CONF1
S1
Sat Number
Satellite number selected for configuration (0-4)
Sat Longitude
Target Satellite Locations Longitudinal Value and Hemisphere
S11/S2A
DVB Carrier Type for target satellite
O (Offset)
Target Satellite Offset
TP Number
Transponder Number in Controller (T0-T2) Horizontal Receive (T3-T5) Vertical Receive
FREQUENCY
Satellite Transponder Frequency that DVB searches
SYMBOL RATE
Satellite Transponder Symbol Rate that DVB searches
CODE RATE
Satellite Transponder FEC (Code) Rate that DVB searches
LNB Power
LNB Power supplied to the LNB when searching for target satellite
SM1
RF Status
RF Search Mode Status, Threshold override status and RF Threshold value
CP
Compass Status (i.e. Normal, Overridden, or Failure)
CP Heading
Compass Angle reading
AZ_W
Azimuth Search Window Limit for satellite acquisition
SM2
Modem ID
Modem Beam ID number
BR Frequency
Beacon Receiver programmable frequency/Initial Acquisition Gain.
CONF2
S2
Sat Longitude
Reference Satellite Locations Longitudinal Value, and Enable/Disable option
O (Offset)
Reference Satellite Offset
TP Number
Transponder Number in Controller (T0-T2) Horizontal Receive (T3-T5) Vertical Receive
FREQUENCY
Satellite Transponder Frequency that DVB searches
S11/S2A
DVB Carrier Type for reference satellite (
SYMBOL RATE
Satellite Transponder Symbol Rate that DVB searches
CODE RATE
Satellite Transponder FEC (Code) Rate that DVB searches
LNB Power
LNB Power supplied to the LNB when searching for reference satellite
MB
MOD FREQ
Frequency modem is configured for (HNS ONLY) (MHz)
MOD sym. Rate
Symbol Rate modem is configured for (HNS ONLY) Sps
Rx/Tx Polarity
Modem configured receive and transmit polarity respectively.
Hem.
Hemisphere of operation
T (N/Y)
Auto Disable Tx when modem is reset while system is online (N=keep modem status)
ACP DIS (Y/N)
Y = Disable ACP N = Enable ACP
22 KHz (E/D)
E = Enable/ D= Disable 22 KHz Tone for HNS Modem
EL
O (Value)
Elevation Offset for proper elevation angle readings
W (Value)
Elevation Window Limit for satellite searching
A (Value)
A (Value) – Elevation Adjustment Gap for inclined surfaces
