iNetVu 7000 Series User Manual

C-COM Satellite Systems Inc. Page 154 of 164
L (UDS)
Up, Down, and Stow Limits enabling (E) or disabling (D) on the Elevation Axis
C (EL Value)
Compass Reading Elevation Angle
S (Value)
Slow Speed Settings for Elevation Angle Operation
I (Limits)
Current Limits on EL Axis @ Speed 9 and @ Speed 6
AZ
Z (Value)
AZ Pot Zero for converting A/D value for physical determination of AZ zero angle
Stow Limit
Stow Limit Enabling (E) or Disabling (D)
CP_O (Value)
Compass Offset
S (Value)
Slow Speed Setting for Azimuth Axis.
I (Limits)
Current Limits on AZ Axis @ Speed 9 and @ Speed 6
PL
Z (Value)
PL Pot Zero for converting A/D value for physical determination of PL zero angle
Skew/Stow Limit
Skew Adjustment and Stow Limit Enabling (E) or Disabling (D)
O (Offset)
Polarization Offset
S (Value)
Slow Speed Setting for Polarization Axis.
I (Limits)
Current Limits on PL Axis @ Speed 9 and @ Speed 6
GP
G (Mode)
GPS Setting (Override, Normal)
GPS Long
GPS Longitudinal Value
GPS Lat
GPS Latitudinal Value
C1
BC
TX Broadcast Enable/Disable
ES_NO
Maximum ES/NO value that will stop peaking process once reached
DH (DHCP)
Enables or Disables DHCP in the controller
UN (Time)
Unattended Operation
MP
Enables or Disables Motion Protection
IN
Inclined Satellite Enable (# -> time between re-peak)
BP
Beep upon Movement of Cursor via LCD
C2
C (Console Use)
Console Interface Configuration (modem, Beacon Receiver, dBUG, GPS, Glonass, PC)
and Baud Rate
Platform Type
Platform Type, Version and Serial Number Configuration
TX_O
Polarization offset adjustment upon positioning due to mechanical misalignment of
mount
C3
PASSWORD
Web Interface, and LCD Configuration Screen Access Password
LO
22KHz Tone
Enable or Disable 22KHz tone
SG
S_IP (Address)
7000 Controller Subnet IP Address
G_IP (Address)
7000 Controller Gateway IP Address
IP
C_IP (Address)
Controller IP Address
M_IP (Address)
Modem IP Address
SR
Service
Service In Use (iDirect, Hughes, Etc.)
Interface
Modem Communication Interface (i.e. Telnet, HTTP, Console, etc.)
Password/CD-
KEY
Modem Password/CD-KEY if necessary
TEST
E&A&P
E (Range)
Range and speed of start angle to end angle of elevation movement
P (Range)
Range and speed of start angle to end angle of polarization movement
A (Range)
Range and speed of start angle to end angle of azimuth movement
Axis Selection
Selection for Axis to be tested, and test looping option setting
TST
Initiates the testing on the specified axis and range.
CP
CP
Performs a Check Compass Operation
DPY
E (Angle)
The target elevation angle for antenna deployment
P (Angle)
The target polarization angle for antenna deployment
A (Angle)
The target azimuth angle for antenna deployment
DPLY
Initiates the deploy command to the specified antenna deployment angles
DPYQ
E (Angle)
The target elevation angle for antenna Quick deployment
P (Angle)
The target polarization angle for antenna Quick deployment
A (Angle)
The target azimuth angle for antenna deployment
DPLY
Initiates the Quick deploy command to the specified antenna deployment angles
DPY_C
E (Angle)
The target elevation angle for antenna deployment and compass reading
P (Angle)
The target polarization angle for antenna deployment and compass reading
A (Angle)
The target azimuth angle for antenna deployment and compass reading
DPLY
DPLY – initiates a compass reading at the specified antenna deployment angles
A_ACP
A_ACP
Initiates an Automatic Cross Pol Test
M_ACP
M_ACP
Initiates a Manual Cross Pol Test
