C-COM Satellite Systems Inc. Page 63 of 164
1 – GPS Status Configuration
N Use Coordinates from GPS Antenna
O Override GPS and use the coordinates entered (2) and (3). Enables the GPS coordinates
to be manually overridden. This should only be enabled in the event that the GPS Antenna
is malfunctioning and the user has a reliable, alternate source for coordinates.
Indicates a situation or practice that might result in
property or equipment damage.
Note 1: If you have overridden the GPS coordinates, they will have to be updated if the
Mobile Platform has moved to a new location since the overridden values will no longer be
accurate.
Note 2: Overriding the GPS will affect movement protection on all mobile platforms
preventing them from automatically stowing if vehicle movement and/or severe motion are
detected. If the vehicle drives off with the platform deployed, it will not stow as it should
because the GPS is overridden. Moving vehicle GPS speed and location must reach min
5km/h and or Elevation angle changes by 2 or more degrees in order for the movement
protection feature to trigger.
2 – GPS Latitude Coordinate
3 – GPS Longitude Coordinate
7.6.4.8. C1
This menu allows for the configuration of the controller input settings as well as the
platform type.
Fig. 46: “C1” Controller Display Screen 1
1 – B (iDirect TX Broadcast)
The 7000 Series Controllers can be configured to broadcast with iDirect service.
This allows iDirect users with broadcast configured modems, to lock onto a DVB
carrier, and enable the transmitter in the iDirect modem automatically after
peaking through the 7000 Series Controller.
D – Disabled
E – Enabled
B :D E S: 130 MS : E DH : D
UN : D IN : D MP : E BP : L
