C-COM Satellite Systems Inc. Page 97 of 164
GPS Override Checkbox
Enables the GPS coordinates to be manually overridden. This should only be enabled in
the event that the GPS Antenna is malfunctioning and the user has a reliable, alternate
source for coordinates. If this box is checked, the GPS coordinates should be manually
entered in the ‘GPS Latitude’, and the ‘GPS Longitude’ fields described.
**Note: If you have overridden the GPS coordinates, they will have to be updated if
the Mobile Platform has moved to a new location since the overridden values will
no longer be accurate.
Warning: Overriding the GPS prevents the movement protection feature from
working properly, and will not stow the antenna if vehicle drives off, as neither
speed nor GPS relocation can be detected. Moving vehicle speed must reach min
5km/h plus Elevation angle change of 2 degrees or more with GPS coordinates
change in order for the movement protection feature to trigger.
GPS Latitude
This field represents the Latitudinal GPS coordinates of the iNetVu
®
system.
GPS Longitude
This field represents the Longitudinal GPS coordinates of the iNetVu
®
system.
Fig. 81: Maintenance – Compass Parameters
Compass Reading Elevation Angle
Number of degrees that the Antenna requires to be elevated to ensure that the compass
is level and is able to acquire an accurate compass reading.
