1 - 25
Transpector XPR 3+ Operating Manual
1.16.11 Attaching Heating Jackets
Heating Jackets for the Transpector XPR 3+ Pirani Interlock Weldment and the
Isolation Valve are installed separately but share a common power cord.
The dual element heater can be operated with 120/230 V(ac) by choosing the
power cord with the appropriate power source connector. Part numbers for the
heaters and power cords are:
Dual element heater for Interlock Weldment
IPN 914-415-P1
Dual element heater for Isolation Valve
IPN 914-407-P1
Power cord for 120 V(AC) operation
IPN 600-1487-P1 and 068-0433
Power cord for 230 V(AC) operation
IPN 600-1487-P2 and 068-0434
The operating temperature of the heater is nominally 150 °C. Thermal
over-temperature protection is built into the heater.
During or immediately after bakeout, the heating jacket
and metal surfaces in the vicinity of the heating jacket
may be hot. These surfaces may exceed 100 °C at the
maximum ambient operating temperature (i.e., 50 °C),
which will cause burns if touched directly without using
the proper personal protection equipment.
1.17 Input/Output (I/O)
This section describes the input and output (I/O) for Transpector XPR 3+.
The Transpector XPR 3+ electronics module supports the following I/O functions
through the AUX I/O connector located on the back panel. See Figure 1-22.
