Transpector XPR 3+ Operating Manual
1.17.3 One Analog Input
One analog input is differential and can handle inputs between 0 to +10 volts and
common mode voltages of 100 volts. See Table 1-4.
NOTE: The analog input is supported through FabGuard software. If the Pirani
interlock option is configured the Pirani gauge reading will use analog
input 1.
Table 1-4 Analog inputs
ANALOG INPUT 1 (+) PIN 9
ANALOG INPUT 1 (-) PIN 10
