Infors HT Multitron - CO 2 Control

Multitron - Operating Manual
Technical Data and Specifications
Page 150 of 158 20 August 2020
Power supply level sensor
Description Type 230 V Type 115 V Unit
Value
Voltage 230 115 VAC
Frequency 50 60 Hz
Connections
Description Value
Water in
Tri-Clamp port DN 8
Inlet pressure: max. 6 bar
12.5.5 CO
2
Control
Connection data
Description
Value
Unit
Connection (hose Ø)
3 to 4
mm
Type of connection Legris
Input pressure
0.5
bar
Various
Description
Value
Unit
Additional mass
0.5
kg
Vaisala CO
2
sensor
Description
Value
Unit
Sensor type
GMP251
Measurement range
0 to 20
% CO
2
Accuracy (at 1013 hPa, 25 °C)
± 0.1
% CO
2
Target and actual CO
2
values
Description
Value
Unit
Setting range
0 to 20
% CO
2
Control range
0.1 to 20
% CO
2
Increment
0.1
% CO
2
Control precision (at 1013 hPa, 20 °C
to 40 °C, up to 20 % CO
2
)
0.2
% CO
2
Gas consump-
tion (ventilation
opening open)
at 5 % CO
2
2
L/h
at 10 % CO
2
3.5
L/h
