Multitron - Operating Manual
Accessories
20 August 2020 Page 59 of 158
Tray with steel clamps
Fitting identical clamps on the entire tray results in the following ca-
pacities:
Flask Size Number of Flasks per M Tray
25 ml 197
50 ml 131
100 ml 91
250 ml 48
300 ml 43
500 ml 31
1000 ml 19
2000 ml 13
3000 ml 9
4000 ml 8
5000 ml 6
Tray with pin holders
For applications in which large numbers of microtitre or deep-well
plates need to be incubated, various trays with pin holders are availa-
ble. These enable loading with several layers of microtitre and deep-
well plates.
The plates can be stacked. This allows you to simultaneously incubate
up to 72 deep-well plates and up to 144 microtitre plates on one M
tray.
The trays are designed for plates with the dimensions 85.1 x 127
mm.
To ensure the cultures receive the optimum oxygen supply, spacers
can be placed between stacked plates. These are available in two var-
iants:
