p2 Section 6. Zones. Version 1.01 CONCEPT IQ. Installation & Programming Manual.
7 Spare
8 * Key Switch Arming A “Key Switch “ Zone will arm the Area it is assigned to when the Zone goes Un-
sealed.
The Zone can be programmed for momentary or latching operation in “General
Options”.
(Address 868, Option 6. Default setting is “Momentary”)
9 * Key Switch HOME A “Key Switch HOME” Zone will Arm the Area it is assigned to in HOME mode
when the Zone goes Un-sealed.
The Zone can be programmed for momentary or latching operation in “General
Options”.
(Address 868, Option 6. Default setting is “Momentary”)
* NOTE: “Key Switch” Zones can be used to Disarm Area 4 when enabled as a Sub-Area, but Area 4 will not
Arm unless all the Areas in the Sub-Area List are Armed.
ZONE OPTIONS (16 Addresses) Defualt = No options Selected
Zone:
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
752 753 754 755 756 757 758 759 760 761 762 763 764 765 766 767
Zone Options allows various processing options to be selected for each individual Zone.
1 Silent When this option is selected, the Zone will not trigger the siren.
2 One-Shot Siren This option allows the Zone to trigger the Siren only once during an arming cycle.
A Zone Restore will be reported on Opening (Area Off).
3 One-Shot Dialer This option allows a Zone to trigger the Dialer only once during an arming cycle.
(“Single Hit”) If Multi-break reporting is required, this option must not be selected.
Highly recommended for “Domestic Dialer” format
4 Pulse Count This option selects the Zone to be Pulse Counted.
The zone will only create an alarm if:
-The “Maximum Pulses” are triggered during the “Pulse Time”.
-OR, the Zone is still in alarm when the “Pulse Time” expires.
These options are programmed in the Global Zone Options described below.
5 Self-Test Zone Any Zones defined as a “Self-Test Zone” are required to go into the un-sealed
state at least once within the “Self-Test Period”, or a Self-Test system input alarm
will be generated.
Self-Test Zones are monitored for activity while the Area that they are assigned
to is Dis-armed. Only Zones that will go into the un-sealed state in the normal
course of daily activity should be defined as a Self-Test Zone. e.g. Movement
detectors and Door contacts that get activated when the system is Dis-armed.
The Self-Test period is programmed in Address 787.
6 Day Alarm Zone If a Zone is defined as a Day Alarm, then when the Area that the Zone is as-
signed to is Dis-armed, the Zone can trigger an Auxiliary that has the “Day
Alarm” Event Type assigned. (Address 816 to 825, Event Type 34)
When the Area is Armed, the Zone will generate an alarm as per it’s Zone Type.
7 Home Zone If a Zone is defined as a Home Zone, it will be Armed when the Area that it is
assigned to is Armed in Home mode.
8 Normally Open. Zones that are defined as “Normally Open” will go into alarm when the alarm
contacts on the device are Sealed, and will restore when the contacts are Un-
sealed. i.e. Reverses the “Seal” and “Alarm” states on the Zone Input.
This option can be used when monitoring devices with Normally Open alarm
contacts are used. e.g. Certain Smoke Detectors, etc.
752
to
767
Data type:
Option
