p4 Section 6. Zones. Version 1.01 CONCEPT IQ. Installation & Programming Manual.
END-OF-LINE RESISTOR TYPE
This data sets the value/s of the End-Of-Line (Terminating) resistor/s used for the Zone inputs. This is a
global setting for all Zone inputs connected to the system.
Single End-Of-Line
0 1K
1 1K5
2 2K2
3 3K3 Default.
4 3K9
5 4K7
6 5K6
7 6K8
8 10K
9 12K
10 22K
The installation kit provides 1k, 3k3 and 6k8 Resistors. Typical “Terminating Resistor” settings will be:
If Single End-Of-Line is used: 3 (3k3)
If Dual End-Of-Line is used: 13 (3k3, 6k8)
If Zone Doubling is used: 14 (1k, 3k3, 6k8)
If the system is replacing another product, and the detectors already have Terminating Resistors of a
different value, the Terminating Resistors may be retained by choosing the setting that matches the
existing values.
ZONE SELF-TEST PERIOD Default = 0
This data sets the number of arming periods to be included in the Zone Self-Test processing.
Any Zone defined as a Self-Test Zone must go un-sealed at least once during this Self-Test period, or a
Self-Test system input alarm will be generated.
A setting from 0 to 16 arming periods can be defined.
Dual End-Of-Line
11 2K2, 2K2
12 2K2, 6K8
13 3K3, 6K8
14 Zone Doubling.* 1k, 3k3, 6K8
15 Zone Doubling.* 1k, 3k3, 6K8 No separate tamper state.
*NOTE: The “Zone Doubling” option allows Zones 1 to 8 on the
Control Module to support two detection devices on each Zone input.
The additional 8 devices will be recognised and processed as Zones 9
to 16. Zone Inputs on the plug-on Zone/Auxiliary Expander board will
be ignored.
786
Data type:
Value
Range:
0 - 15
787
Data type:
Value
Range:
0 - 16
