p6 Section 10. Comms. Version 1.01 CONCEPT IQ. Installation & Programming Manual.
Contact ID Events
* By Keyswitch / Remote / TimeZone / etc.
Each event in Contact ID is sent as a string of 16 DTMF digits. For example, an alarm followed by a restore and then an
opening would be 3 events. All Contact ID strings follow the format: CCCC 18 SXYZ GG PPP K where:
CCCC 4 digit client code that identifies the panel or site.
18 Always the digits “18”.
SXYZ Event code.
S = Status. 1 - Alarm or Opening. 3 - Restore or Closing. (Note: Alarm Restores only reported on Area Opening)
XYZ = Type of Event.
GG Group Byte which signifies the Area being Opened/Closed or the Area in which the alarm occurred.
PPP Point ID. This refers to either the Point number or the User ID depending on the type of event.
K Checksum.
Some receivers display a “U” (User) or a “C” (Alarm Point) in front of the PPP, depending on which of these PPP represents.
TYPE OF ALARM MESSAGE EVENT CODE GROUP BYTE (AREA) POINT ID
Zone Type (Zone Inputs) XYZ GG PPP
0 - Instant (Burglary) 130 01 to 04 001 to 016
1 - Delayed (Entry/Exit) 130 01 to 04 001 to 016
2 - Handover 130 01 to 04 001 to 016
3 - 24hr Burglary 130 01 to 04 001 to 016
4 - 24hr Fire 110 01 to 04 001 to 016
5 - 24hr Panic 120 01 to 04 001 to 016
6 - 24hr Duress 121 01 to 04 001 to 016
Tamper 144 01 to 04 001 to 016
Isolate 570 01 to 04 001 to 016
System Inputs ^ = Restore not reported.
AC Fail 301 01 101
Low Battery 302 01 102
Cabinet Tamper 145 01 103
Siren Monitor Alarm 320 01 104
LAN Fuse fail 140 01 105
Battery Fuse fail 140 01 106
Comms Fail 354 01 107 ^
System Reset 305 01 108 ^
Keypad Lockout 140 01 109 ^
Zone Self Test Fail 307 01 110 ^
Keypad Medical Alarm 120 01 111 ^
Keypad Panic Alarm 120 01 112 ^
Keypad Duress Alarm 121 01 113 ^
Keypad Fire Alarm 110 01 114 ^
Program Altered 306 01 115 ^
Door Alarm. Door 1 140 01 116 ^
Door Alarm. Door 2 140 01 117 ^
Door Alarm. Door 3 140 01 118 ^
Door Alarm. Door 4 140 01 119 ^
Test Report 602 01 120 ^
System Input Isolate 570 01 101 to 120
Open / Close
By User PIN code - Single Area 401 01 to 04 001 to 047
By User PIN code - General Open/Close 402 00 001 to 047
By System* - Single Area 403 01 to 04 48
By System* - General Open/Close 402 00 48
Quick Arm 408 01 to 04 48
