Reject escrow
173
Status
182
Enable all
184
Disable all
185
Disable escrow timeout
190
Enable escrow timeout
191
Example transactions are shown below (see table 13):
Event
Validator
Decimal
Value
Host
Note entered into validator
Validator Busy
120➔
Note accepted channel 2
Validator Ready
121➔
Accept on channel 2
2➔
Note entered into validator
Validator Busy
120➔
Note not recognised
Validator Ready
121➔
Note not recognised
20➔
Validator has returned note
Validator Ready
121➔
Software Inhibit Channel 4
Inhibit C4
134
Inhibit C4
Channel 4 inhibited
134➔
Software Enable Channel 4
Uninhibit C4
154
Uninhibit C4
Channel 4 inhibited
154➔
Status Report
182
Status Request
Status Requested
182➔
3 byte status message
Inhibit status Channels 1-8
Byte 1➔
Inhibit status Channels 9-16
Byte 2➔
Escrow On (=1) / Off (=0)
Byte 3➔
Turn on Escrow Mode
 170
Enable Escrow
Mode
Escrow Mode Enabled
170➔
Note accept in Escrow Mode
Note entered into validator
Validator Busy
120➔
Note Accepted Channel 2
Validator Ready
121➔
Accept on Channel 2
2➔
172
Accept Note in
Escrow
Accept Escrow
172➔
Accept on Channel 2
2➔
