Ventway Sparrow User Manual
Page 30 of 144
6. CONNECTING THE VENTILATOR
6.1. FRONT PANEL CONNECTIONS
6.2. REAR PANEL CONNECTIONS
1. Air inlet/Oxygen supply connector Air inlet/ oxygen connector to Oxygen Mixer
(see Section 12.1.1.1. Connecting the Air Inlet to the Oxygen Mixer
).
2. DC Power connector Connect power line (AC/DC or DC/DC power supply)
Caution: Insert the three-conductor plug into a properly wired, three-wire, grounded,
hospital grade receptacle. If a three-wire receptacle is not available, a qualified electrician
must install one in accordance with the governing electrical code. Do not under any
circumstances remove the grounding connector from the power plug. Do not use
extension cords or adapters of any type. The power cord and plug must be intact and
undamaged.
3. USB connector This connector is intended for technicians who require access to
the logbook and device software.
4. Power On/Off button
5. Battery safety lock
6. Battery pack
7. Filter compartment screws
8. Anti asphyxia valve
1
Pressure and flow measurement port
2
Pressure measurement port
3
Expiratory valve port control tube
4
Ventilator gas outlet
Page 30 of 144
