Ventway Sparrow User Manual
Page 141 of 144
23.22. START-UP DURING VENTILATION
Step Procedure Action Expected Results
1 Start up the Sparrow ventilator.
Complete the patient circuit test.
The software switches to the
ventilation phase, weight selection
screen.
2 Set the simulator to the patient weight of
70 kg.
Select 70 kg and then SIMV ventilation
mode, Invasive/Non-Invasive, and confirm
the patient connection.
Mode is set. The blower starts.
The software switches to running
ventilation, in SIMV mode.
3 Change the desired BPM in the run screen
to 13
The ventilator starts ventilating 13
breaths per minute.
4 Change the desired Volume to 500cc.
The ventilator starts ventilating in
500cc breaths.
5 Enter the Menu -> Alarm settings The screen title
should be
“ALARMS(1/2)”
6 Change all the alarm settings in both alarms
settings screens.
All alarm settings are changed.
7 While ventilating, disconnect the external
charger and remove the battery.
The ventilator turned off.
8 Reconnect the external charger within 2
minutes and turn the ventilator on.
The ventilator should notify
“unexpected shutoff” and continue
ventilating using the previous settings.
9 Check and see that all settings are the same
as before the restart.
All settings
should be the same as
before the restart.
10 Disconnect the charger. The ventilator should turn off.
11 Wait longer than 2 minutes, reconnect the
charger and turn the ventilator on.
The ventilator should show a message
for an “unexpected shutoff” and give
the option to continue ventilating.
12 Select Ok
The ventilator should continue
ventilating using previous settings.
13 Enter Menu -> Adv. Settings and press
“Load default”.
A warning saying “Reset to default
settings” should appear
14 Press ok The warning popup should disappear
