Integra DTR-20.1 User Manual

62
Advanced Setup—Continued
SurrBack ch
*5
2ch: Select if two (left and right) surround back speakers are connected.
1ch: Select if only one surround back L speaker is connected.
*1 If the “Subwoofer” setting is set to “No”, the “Front” setting is fixed at “Full Band”.
*2 If the “Front” setting is set to anything other than “Full Band”, “Full Band” cannot be selected here.
*3 If the “Surr” setting is set to “None”, this setting cannot be selected.
*4 If the “Surr” setting is set to anything other than “Full Band”, “Full Band” cannot be selected here.
*5 If the “Surr” or “SurrBk” settings are set to “None”, this setting does not appear.
LPF of LFE 80Hz, 90Hz, 100Hz (default), 110Hz, 120Hz
(Low-Pass Filter for the LFE Channel)
This setting is not set automatically by the Audyssey 2EQ
™ Room Correction and Speaker Setup function
(see page 35).
With this setting, you can specify the cutoff frequency of the LFE channel’s low-pass filter (LPF), which can be
used to filter out unwanted hum. The LPF only applies to sources that use the LFE channel.
Double Bass
This setting is not set automatically by the Audyssey 2EQ Room Correction and Speaker Setup function
(see page 35).
With the Double Bass function, you can boost bass output by feeding bass sounds from the front left, right, and
center to the subwoofer. This function can be set only if the “Subwoofer” setting is set to “Yes”, and the “Front”
setting is set to “Full Band” in the “2-1. Sp Config (Speaker Configuration)” on page 61.
On: Double Bass function on (default).
Off: Double Bass function off.
2-2. Sp Distance (Speaker Distance)
These settings are set automatically by the Audyssey 2EQ Room Correction and Speaker Setup function (see page 35).
With these settings, you can specify the distance from each speaker to the listening position.
Measure and make a note of the distance from each speaker to the listening position.
Notes:
• Speakers that you set to “No” or “None” in the “2-1. Sp Config (Speaker Configuration)” (page 61) cannot be
selected.
• The speaker distance setting cannot be changed while a pair of headphones is connected.
• The Center and Subwoofer distances can be set up to 5 ft. (1.5 m) more or less than the Left distance. For example,
if the Left distance is set to 20 ft. (6 m), the Center and Subwoofer distances can be set between 15 and 25 ft. (4.5
and 7.5 m).
• The Surround and Surround Back distances can be set up to 5 ft. (1.5 m) more or 15 ft. (4.5 m) less than the Left
distance. For example, if the Left distance is set to 20 ft. (6 m), the SurrRight, Surr Left, Surr Back R, and Surr Back
L distances can be set between 5 and 25 ft. (1.5 and 7.5 m).
Unit feet: Distances can be set in feet. Range: 0.5 to 30 feet in 0.5-foot steps.
meters: Distances can be set in meters. Range: 0.15 to 9 meters in 0.15-meter steps.
Left, Center, Right, Surr R, SurrBk R, SurrBk L, Surr L, Subwoofer
Specify the distance from the each speaker to your listening position.
DTR-20.1_En_A.book Page 62 Wednesday, April 8, 2009 10:06 PM
