Integra DTR-20.1 User Manual

93
Specifications
Amplifier Section
Video Section
Tuner Section
General
■ Video Inputs
■ Video Outputs
■ Audio Inputs
■ Audio Outputs
■ Control Terminal
Specifications and features are subject to change without
notice.
Rated Output Power
All channels: 90 watts minimum continuous power
per channel, 8 ohm loads, 2 channels
driven from 20Hz to 20kHz, with a
maximum total harmonic distortion of
0.08% (FTC)
105 watts minimum continuous power
per channel, 8 ohm loads, 2 channels
driven at 1kHz, with a maximum total
harmonic distortion of 0.7% (FTC)
110 watts minimum continuous power
per channel, 6 ohm loads, 2 channels
driven at 1kHz, with a maximum total
harmonic distortion of 0.1% (FTC)
Dynamic Power 210 W (3Ω, Front)
180 W (4Ω, Front)
110 W (8Ω, Front)
THD (Total Harmonic Distortion)
0.08% (1kHz, 1 W)
Damping Factor 60 (Front, 1kHz, 8Ω)
Input Sensitivity and Impedance
200 mV/ 47 kΩ (LINE)
Output Level and Impedance
200 mV/ 2.2 kΩ (REC OUT)
Frequency Response 5Hz–100kHz/ +1 dB–3 dB (Direct mode)
Tone Control ±10 dB, 50Hz (BASS)
±10 dB, 20kHz (TREBLE)
Signal to Noise Ratio 106 dB (LINE, IHF-A)
Speaker Impedance 6Ω – 16Ω
Input Sensitivity/Output Level and Impedance
1 Vp-p /75Ω (Component Y)
0.7 Vp-p /75Ω (Component Pb/Cb, Pr/Cr)
1 Vp-p /75Ω (Composite)
Component Video Frequency Response
5Hz – 50MHz, –3 dB
FM Tuning Frequency Range
87.5 MHz – 107.9 MHz
AM Tuning Frequency Range
530 kHz – 1710 kHz
Preset Channel 40
Power Supply
AC 120 V, 60Hz
Power Consumption
4.9 A
Dimensions (W × H × D)
435 × 175 × 326.5 mm
17-1/8" × 6-7/8"× 12-7/8"
Weight
10.5 kg
23.1 lbs.
HDMI IN 1, IN 2, IN 3, IN 4
Component IN 1, IN 2
Composite DVD/BD, VCR/DVR, CBL/SAT, GAME
HDMI OUT
Component OUT
Composite VCR/DVR (REC OUT),
MONITOR OUT
Digital Inputs COAXIAL: 2
OPTICAL: 2
Analog Inputs DVD/BD, VCR/DVR, CBL/SAT, CD,
GAME, TV/TAPE
Analog Outputs TV/TAPE, VCR/DVR, ZONE2 PRE OUT
Pre Outputs 2 ch (SBL, SBR)
Subwoofer Pre Outputs 2
Speaker Outputs Main (L, R, C, SL, SR)
Phones 1
MIC Yes
RS232 1
Ethernet 1
IR Input/Output 2/1
12 V Trigger Out 3
DTR-20.1_En_A.book Page 93 Wednesday, April 8, 2009 10:06 PM
