A PARTS LIST
A-3
39 7
R17, R23, R24, R25,
R26, R27, R28
Resistor, 1/8W, 10K, 5% BCRY8103JT Beckman
40 1 R21 Resistor, 1/8W, 10, 5% BCRY8100JT Beckman
41 1 R4 Resistor, 1/8W, 24.9K, 1% BCRY82492FT Beckman
42 2 R3 Resistor, 1/8W, 35.7K, 1% BCRY83572FT Beckman
43 3 R11, R14, R29 Resistor 1/8W, 00, 5% FRJ-55P5489121 Vishay-Dale
44 10
R2, R5, R7, R9, R10,
R13, R30, R31, R32,
R33
Resistor, 1/8W, 470, 5% BCRY8471JT Beckman
45 1 R20 Resistor, 1W, 0.04, 5% WSL-2512-R040 Vishay-Dale
46 5
R8, R16, R18, R19,
R22
Resistor Package, 22 ohms 4814P-T01-220 Bourns
47 2 R1, R6 Resistor Package, 1K 4816P-T02-102 Bourns
48 1 R15 Resistor Package, 4.7K 4816P-T02-472 Bourns
49 1 S1 DIP Switch DHS-45 Mors-Asc
50 1 S2 Push Button Switch EP12-D1A-BE C&K
51 1
U16
IC TL7705ACD
Texas
Instruments
52 1 Y1 Crystal KDS143-20 KDS America
53 1 U14 IC Z0853606VSC Zilog
54 1 U18 FPGA iFX780-84-10 Intel
55 1 U28 PAL N85C220-10 Intel
56 1 R34 Resistor, 1/8 W, 2.2K, 5% BCRY8222JT Beckman
Table A-1. Cyclone EP/PCI-SDK Platform Bill Of Materials (Sheet 3 of 3)
CYCLONE EVALUATION PLATFORM Revised: December 1, 1994
CFEVALBD.SCH Revision: 0.0
Bill Of Materials
Reference Description Mfg. Part # Manufacturer
