On
-board Con
nector/Header Over
view
Intel®
Server
Board S1200V3RP
TPS
Revision 1.2
86
8.5.6
I/O Module Connector
The follow
ing table details the pin-out de
f
inition
of the I/O Mod
ule connector (J1C1).
Table
51
.
I/O Mo
dule Connector P
in-out (J
1C1)
Pin
Signal Name
Pin
Signal Name
1
P3V3
2
P12V
3
P3V3
4
P12V
5
P3V3
6
P12V
7
P3V3
8
P12V
9
RSVD_PIN9
10
FRU_TEMP_ADDR
11
GND
12
P5V_AUX
13
RSVD_PIN13
14
FM_IOM_EN
15
RSVD_PIN15
16
P3V3_AUX
17
GND
18
LED _ACT_N
19
RSVD_PIN19
20
RPESENT_N
21
RSVD_PIN21
22
W
AKE_N
23
GND
24
RESET_N
25
SMB_3V3SB_CLK
26
GND
27
SMB_3V3SB_DAT
28
CLK_100M_DP
29
GND
30
CLK_100M_DN
31
PE_TN_7
32
GND
33
PE_TP_7
34
PE_RN_7
35
GND
36
PE_RP_7
37
PE_TN_6
38
GND
39
PE_TP_6
40
PE_RN_6
41
GND
42
PE_RP_6
43
PE_TN_5
44
GND
45
PE_TP_5
46
PE_RN_5
47
GND
48
PE_RP_5
49
PE_TN_4
50
GND
51
PE_TP_4
52
PE_RN_4
53
GND
54
PE_RP_4
55
PE_TN_3
56
GND
57
PE_TP_3
58
PE_RN_3
59
GND
60
PE_RP_3
61
PE_TN_2
62
GND
63
PE_TP_2
64
PE_RN_2
65
GND
66
PE_RP_2
67
PE_TN_1
68
GND
69
PE_TP_1
70
PE_RN_1
71
GND
72
PE_RP_1
73
PE_TN_0
74
GND
75
PE_TP_0
76
PE_RN_0
77
GND
78
PE_RP_0
79
RSVD_PIN79
80
GND
