Platform Management Functional Overview Intel® Server Board S1200V3RP TPS
Revision 1.2
52
Both Static and Dynamic CLTT modes implement a Hybrid Closed Loop Thermal Throttling
mechanism whereby the Integrated Memory Controller estimates the DRAM temperature in
between actual reads of the memory thermal sensors.
6.11 Messaging Interfaces
The BMC supports the following communications interfaces:
 Host SMS interface by means of low pin count (LPC)/keyboard controller style (KCS)
interface
 Host SMM interface by means of low pin count (LPC)/keyboard controller style (KCS)
interface
 Intelligent Platform Management Bus (IPMB) I2C interface
 LAN interface using the IPMI-over-LAN protocols
Every messaging interface is assigned an IPMI channel ID by IPMI 2.0. The following table
shows the standard channel assignments.
Table 19. Messaging Interfaces
Channel ID
Interface
Supports
Sessions
0
Primary IPMB
No
1
LAN 1
Yes
2
LAN 2
Yes
3
LAN3
1
(Provided by the Intel
®
Dedicated Server
Management NIC)
Yes
4
Reserved
Yes
5
USB
2
No
6
Secondary IPMB
No
7
SMM
No
8 – 0Dh
Reserved
–
0Eh
Self
3
–
0Fh
SMS/Receive Message Queue
No
Notes:
1. Optional hardware supported by the server system.
2. Reserve USB channel number, current BMC firmware does not support communication through a USB
channel.
3. Refers to the actual channel used to send the request.
6.11.1 User Model
The BMC supports the IPMI 2.0 user model. 15 user IDs are supported. These 15 users can be
assigned to any channel. The following restrictions are placed on user-related operations:
1. User names for User IDs 1 and 2 cannot be changed. These are always “” (Null/blank)
and “root” respectively.
