Intel® Server Board S1200V3RP TPS Jumper Blocks
Revision 1.2
10. Jumper Blocks
The server board includes several 3-pin jumper blocks which are used to as part of a process to
restore a board function back to a normal functional state. The following diagram and sections
identify the location of each jumper block and provides a description of their use.
The following symbol identifies Pin 1 on each jumper block on the silkscreen:
Figure 47. Jumper Blocks (J2K6, J2K8, J2K9, J3K2, J3K6)
Note:
1. For safety purposes, the power cord should be disconnected from a system before removing
any system components or moving any of the on-board jumper blocks.
2. System Update and Recovery files are included in the System Update Packages (SUP)
posted to Intel’s website.
