Intel S1200V3RP Technical Product Specification

On-board Connector/Header Overview Intel® Server Board S1200V3RP TPS
Revision 1.2
84
Table 45. External DB9 Serial A Port Pin-out (J9A1)
Pin
Signal Name
Description
1
SPA_DCD
DCD (carrier detect)
2
SPA_SIN_N
RXD (receive data)
3
SPA_OUT_N
TXD (Transmit data)
4
SPA_DTR
DTR (Data terminal ready)
5
GND
Ground
6
SPA_DSR
DSR (data set ready)
7
SPA_RTS
RTS (request to send)
8
SPA_CTS
CTS (clear to send)
9
SPA_RI
RI (Ring Indicate)
Table 46. Internal 9-pin Serial B Header Pin-out (J9A2)
Pin
Signal Name
Description
1
SPB_DCD
DCD (carrier detect)
2
SPB_DSR
DSR (data set ready)
3
SPB_SIN_N
RXD (receive data)
4
SPB_RTS
RTS (request to send)
5
SPB_OUT_N
TXD (Transmit data)
6
SPB_CTS
CTS (clear to send)
7
SPB_DTR
DTR (Data terminal ready)
8
SPB_RI
RI (Ring indicate)
9
GND
Ground
10
KEY PIN
No pin
8.5.5 USB Connector
One 2x5 connectors on the server board (J1K3) provides support for two additional USB 2.0
ports. J1K3 is recommended for front panel USB ports.
Table 47. Internal USB2.0 Connector Pin-out (J1K3)
Pin
Signal Name
Description
1
USB_PWR_5V
USB power
2
USB_PWR_5V
USB power
3
USB _PN_CONN
USB port negative signal
4
USB _PN_CONN
USB port negative signal
5
USB _PP_CONN
USB port positive signal
6
USB _PP_CONN
USB port positive signal
7
GND
Ground
8
GND
Ground
9
KEY PIN
No pin
10
TP_USB _NC
Test point
One 2x10 connectors on the server board (J1J1) provides support for two additional USB 3.0
ports. J1J1 is recommended for front panel USB ports.
