Intel S1200V3RP Technical Product Specification

Appendix E: Supported Intel® Server Chassis Intel® Server Board S1200V3RP TPS
Revision 1.2
252
Appendix E: Supported Intel
®
Server Chassis
The Intel
®
Server Board S1200V3RP requires a passive processor heat sink solution when
integrated in the Intel
®
pedestal server chassis listed below. The Intel
®
Server Board
S1200V3RP supports up to 95W TDP Intel
®
Xeon
®
Processor.
Table 79. Compatible Intel
®
Server Chassis P4000S family
Intel
®
Server Chassis SKU
System Fans
Storage Drives
Power Supply(s)
P4304XXSHDR
Two Fixed Fans
Four 3.5” Hotswap Drive Bay
Two 460W CRPS
P4304XXSFDR
Two Fixed Fans
Four 3.5” Fixed Drive Trays
Two 460W CRPS
You must install the active processor heat sink with the airflow direction as shown in the
following figure.
Figure 54. Processor Heatsink Installation
