Intel S1200V3RP Technical Product Specification

Functional Architecture Intel® Server Board S1200V3RP TPS
Revision 1.2
20
 Direct Media Interface (DMI)
Direct Media Interface (DMI) connects the processor and the PCH. DMI2.0 is supported.
Note: Only DMI x4 configuration is supported.
- DMI 2.0 support.
- Compliant to Direct Media Interface Second Generation (DMI2).
- Four lanes in each direction.
- 5 GT/s point-to-point DMI interface to PCH is supported.
3.3.5 Intel
®
Integrated RAID Option
The Intel
®
Server Board S1200V3RPL, S1200V3RPO, and S1200V3RPM provide a SAS/ROC
Mezzanine slot (J4J1) to a high density 80-pin connector labeled SAS_MOD for the installation
of an optional Intel
®
Integrated RAID Module. For more information, please refer to Table 5.
Features of this option include:
 SKU options to support full or entry level hardware RAID
 Dual-core 6Gb SAS ROC/IOC (LSI* 2208)
 4 or 8 port and SAS/SATA or SATA – only ROC options
 SKU options to support 512MB or 1GB embedded memory
 Intel
®
designed flash plus optional support for Intel
®
RAID Maintenance Free Backup
Units (AXXRMFBU2) or improved Lithium Polymer battery
Table 6. Supported Intel
®
Integrated RAID Modules
External Name
Description
Product Code
Intel
®
Integrated RAID Module
RMS25CB080
8 Port SAS-2.1, Full HW RAID, 1GB, IOM
Slot
RAID Levels 0,1,10, 5, 50, 6, 60
RMS25CB080
Intel
®
Integrated RAID Module
RMS25CB040
4 Port SAS-2.1, Full HW RAID, 1GB, IOM
Slot
RAID Levels 0,1,10, 5, 50, 6, 60
RMS25CB040
Intel
®
Integrated RAID Module
RMT3CB080
8 Port SATA-3, Full HW RAID, 512MB,
IOM Slot
RAID Levels 0,1,10, 5, 50, 6, 60
RMT3CB080
Intel
®
Integrated RAID Module
RMS25KB080
8 Port SAS-2.1, Entry-level HW RAID,
IOM Slot
RAID Levels 0,1,1E
RMS25KB080
Intel
®
Integrated RAID Module
RMS25KB040
4 Port SAS-2.1, Entry-level HW RAID,
IOM Slot
RAID Levels 0,1,1E
RMS25KB040
For additional product information, refer to the document Intel
®
Integrated RAID Module
RMS25KB080, RMS25KB040, RMS25CB080, and RMS25CB040 Hardware User’s Guide.
3.3.6 Optional I/O Module Support
To broaden the standard on-board feature set, the Intel
®
Server Board S1200V3RPO and
S1200V3RPM provide support for one of several available IO Module options. The I/O module
