Intel S1200V3RP Technical Product Specification

Intel® Server Board S1200V3RP TPS BIOS Setup Interface
Revision 1.2
95
 In the Option Values entry, the text for default values is shown with an underline. These
values do not appear underline on the BIOS Setup screen. The underlined text in this
document is to serve as a reference to which value is the default value.
 The Help Text entry is the actual text which appears on the screen to accompany the
item when the item is the one in focus (active on the screen).
 The Comments entry provides additional information where it may be helpful. This
information does not appear on the BIOS Setup screens.
 Information enclosed in angular brackets (< >) in the screen shots identifies text that can
vary, depending on the option(s) installed. For example, <Amount of memory installed>
is replaced by the actual value for “Total Memory”.
 Information enclosed in square brackets ([ ]) in the tables identifies areas where the user
must type in text instead of selecting from a provided option.
 Whenever information is changed (except Date and Time), the systems requires a save
and reboot to take place in order for the changes to take effect. Alternatively, pressing
<ESC> discards the changes and resumes POST to continue to boot the system
according to the boot order set from the last boot.
9.4.2.1 Map of Screens and Functionality
There are a number of screens in the entire Setup collection. They are organized into major
categories. Each category has a hierarchy beginning with a top-level screen from which lower-
level screens may be selected. Each top-level screen appears as a tab, arranged across the top
of the Setup screen image of all top-level screens.
There are more categories than will fit across the top of the screen, so at any given time there
will be some categories which will not appear until the user has scrolled across the tabs which
are present.
The categories and the screens included in each category are listed as follows, with links to
each of the screens named:
Table 57. Screen Map
Categories (Top Tabs)
2nd Level Screens
3rd Level Screens
Main Screen (Tab)
Advanced Screen (Tab)

Processor Configuration


Memory Configuration


Mass Storage Controller
Configuration

PCI Configuration

NIC Configuration

Serial Port Configuration

USB Configuration

System Acoustic and Performance
Configuration

Network Stack
