Intel S1200V3RP Technical Product Specification

Intel® Server Board S1200V3RP TPS Platform Management Functional Overview
Revision 1.2
61
Table 20. Factory Configured PEF Table Entries
Event Filter
Number
Offset Mask
Events
1
Non-critical, critical and non-
recoverable
Temperature sensor out of range
2
Non-critical, critical and non-
recoverable
Voltage sensor out of range
3
Non-critical, critical and non-
recoverable
Fan failure
4
General chassis intrusion
Chassis intrusion (security
violation)
5
Failure and predictive failure
Power supply failure
6
Uncorrectable ECC
BIOS
7
POST error
BIOS: POST code error
8
FRB2
Watchdog Timer expiration for
FRB2
9
Policy Correction Time
Node Manager
10
Power down, power cycle, and
reset
Watchdog timer
11
OEM system boot event
System restart (reboot)
12
Drive Failure, Predicted Failure
Hot Swap Controller
Additionally, the BMC supports the following PEF actions:
 Power off
 Power cycle
 Reset
 OEM action
 Alerts
The Diagnostic interrupt action is not supported.
6.11.10 LAN Alerting
The BMC supports sending embedded LAN alerts, called SNMP PET (Platform Event traps),
and SMTP email alerts.
The BMC supports a minimum of four LAN alert destinations.
6.11.10.1 SNMP Platform Event Traps (PETs)
This feature enables a target system to send SNMP traps to a designated IP address by means
of LAN. These alerts are formatted per the Intelligent Platform Management Interface
Specification Second Generation v2.0. A Modular Information Block (MIB) file associated with
the traps is provided with the BMC firmware to facilitate interpretation of the traps by external
software. The format of the MIB file is covered under RFC 2578.
