Intel S1200V3RP Technical Product Specification

BIOS Setup Interface Intel® Server Board S1200V3RP TPS
Revision 1.2
132
26. IOM2 Port3 PXE
27. IOM2 Port4 PXE
Option Values: Enabled
Disabled
Help Text:
Enable/Disable Onboard/IOM NIC Port PXE Boot
Comments: This will enable or disable PXE Boot capability for Port<x, x = 1-4>
of Onboard NIC<n, n = 1-2> or IO Module<n, n = 1-2>.
This option will not appear for ports on a NIC which is Disabled, or for individual ports
when the corresponding NIC Port is disabled.
Only ports which actually exist for a particular NIC or IOM will appear in this section.
That is, Port1-Port4 will appear for a quad-port NIC, Port1-Port2 will appear for a dual-
port NIC, and only Port1 will appear for a single-port NIC.
The default state of each Port PXE Boot option is Enabled, if the corresponding PXE
Boot OPROM of the same speed is Enabled. If a PXE Boot OPROM for 1 GbE or 10
GbE changes from Disabled to Enabled, then the Port PXE Boot option becomes
Enabled for all ports of that speed
If the PXE Boot OPROM for1 GbE NICs or 10 GbE NICs is disabled, PXE Boot will be
disabled and grayed out as unchangeable for all ports on NICs or IO Modules of that
same speed.
Conversely, if PXE Boot is disabled for all ports of a given speed, the corresponding
PXE Option ROM will be disabled but not grayed out since it could be selected.
Back to [NIC Configuration Screen] — [PCI Configuration Screen] — [Advanced Screen]
— [Screen Map]
28. NIC1 Port1 MAC Address
29. NIC2 Port1 MAC Address
30. IOM1 Port1 MAC Address
31. IOM1 Port2 MAC Address
32. IOM1 Port3 MAC Address
33. IOM1 Port4 MAC Address
34. IOM2 Port1 MAC Address
35. IOM2 Port2 MAC Address
